Pressure Sensor Characteristics Maximum Ratings
Environmental Specifications
Supply Voltage, Vs
16 Vdc
Temperature Ranges
Common-mode pressure
Lead Temperature
(soldering 2-4 sec.)
Standard Pressure Ranges
10 psig
250°C
Compensated
Operating
Storage
Humidity Limits
0 to 50(70)° C
-25 to 85° C
-40 to 125° C
0 to 95% RH
(non condensing)
Single in Line Packages-SIP
One Port
Two Ports Same Side
Two Ports Opposite Side
Part Number
2 INCH-G-MV-MINI
5 INCH-G-MV-MINI
10 INCH-G-MV-MINI
20 INCH-G-MV-MINI
30 INCH-G-MV-MINI
Operating Pressure
0 - 1 “H2O
0 - 2 “H2O
0 - 5 “H2O
0 - 10 “H2O
0 - 20 “H2O
0 - 30 “H2O
Part Number
2 INCH-D1-MV-MINI
5 INCH-D1-MV-MINI
10 INCH-D1-MV-MINI
20 INCH-D1-MV-MINI
30 INCH-D1-MV-MINI
Part Number
1 INCH-D2-MV-MINI
2 INCH-D2-MV-MINI
5 INCH-D2-MV-MINI
10 INCH-D2-MV-MINI
20 INCH-D2-MV-MINI
30 INCH-D2-MV-MINI
Dual in Line Packages
One Port
Two Ports Same Side
Two Ports Opposite Side
Part Number
2 INCH-GDIP-MV-MINI
5 INCH-GDIP-MV-MINI
10 INCH-GDIP-MV-MINI
20 INCH-GDIP-MV-MINI
30 INCH-GDIP-MV-MINI
Operating Pressure
0 - 2 “H2O
0 - 5 “H2O
0 - 10 “H2O
0 - 20 “H2O
0 - 30 “H2O
Part Number
2 INCH-D1DIP-MV-MINI
5 INCH-D1DIP-MV-MINI
10 INCH-D1DIP-MV-MINI
20 INCH-D1DIP-MV-MINI
30 INCH-D1DIP-MV-MINI
Part Number
2 INCH-D2DIP-MV-MINI
5 INCH-D2DIP-MV-MINI
10 INCH-D2DIP-MV-MINI
20 INCH-D2DIP-MV-MINI
30 INCH-D2DIP-MV-MINI
Performance Characteristics for 1 INCH-D2-MV-MINI
Parameter, note 1
Operating Range, differential pressure
Output Span, @ 1 “H2O, note 5
Offset Voltage @ zero differential pressure
Offset Temperature Shift (0°C-50°C), note 2
Offset Warm-up Shift, note 3
Offset Position Sensitivity (1g)
Offset Long Term Drift (one year)
Linearity, hysteresis error, note 4
Span Shift (0°C-50°C), @ 1 “H2O, note 2
Minimum
8.0
Nominal
1.0
10
0.05
Maximum
12.0
±500
±250
±100
±50
±200
0.25
±300
Units
“H2O
mV
mV
uV
uV
uV
uV
%fs
uV
MiniatureLowPressureSensors
